Jiangsu Bestech Industrial Co., Ltd.
|
Model No. |
BT500 |
|
Taper of spindle bore |
113(1.20) |
|
Spindle number of speeds |
12 STEPS |
|
Spindle range of speeds |
36-1600/13-1400 rpm |
|
Threads metric pitches |
1-14mm/22 |
|
Threads imperial pitches |
28-2TPI/26 |
|
Threads diametral pitches |
56-4DP/24 |
|
Threads module pitches |
0.5-7mm/18 |
|
Range of feeds longitudinal |
0.063-2.52mm(0.023"-0.937") |
|
Range of feeds cross |
0.027-1.07mm(0.011"-0.404") |
|
External diameter of the tailstock quill |
Ø75mm |
|
Max.traverse of the tailstock quill |
150 |
|
Quill taper |
No.5(morse) |
|
Max.travel of compound rest |
145mm |
|
Max.cross slide travel |
360mm |
|
Max.size of tool shank(W*H) |
25x25mm |
|
Power of the main motor |
7.5kw |
|
Overall dimensions L*W*H |
(2700/3200/3700/4200/4700/5700)x1150x1800mm |
|
Net weight |
2850/3150/3400/3800/4200/4700kg |
