| Model | Z3080x20A |
Z3080X25A |
|
Max. drilling diameter |
80 |
80 |
|
Distance from spindle nose to table surface |
350-1570 |
350-1570 |
|
Distance between spindle axis and column surface |
510-2000 |
480-2500 |
|
Spindle travel |
400 |
400 |
|
Spindle taper |
6 |
6 |
|
Spindle speeds range |
16-1600 |
16-1600 |
|
Spindle speed step |
16 |
16 |
|
Spindle feeding ranger |
0.04-3.20 |
0.04-3.20 |
|
Spindle feeding step |
16 |
16 |
|
Rocker rotary angle |
+/-90 |
+/-90 |
|
Main motor power |
7.5 |
7.5 |
|
Movement motor power |
1.5 |
1.5 |
|
N/W |
7000 |
9500 |
|
Overall dimensions(L*W*H) |
2980*1250*3300 |
3500*1450*3300 |
