BT16 brushless motor milling and drillin

BT16 brushless motor milling and drilling machine with low price

Model No.:BT16
Max. drilling capacity: 16mm
Max end milling capacity :13mm
Max. face milling capacity :30mm
Table size:410x112mm / 460x112mm

Product Detail
Accessories

● Wide range of applications
● Expansion bellow as guide protection
● Spindle sleeve feed via star grip (drilling).
● Stable and precise dovetail control adjustable with V-ledges.

Model No.	BT16
Cross travel (X)	110mm/130mm
Longitudinal travel	250mm/300mm
Spindle stroke	180mm
Head swivel	45 degree at left or right
Step of spindle speeds	Variable speed
Angle of spindle speeds	20-2250rpm
Distance from spindle nose to table	220mm
Motor	550W
Net/Gross weight	62 kg/ 80kg
Packing size	570x510x740mm/ 640x565x720mm

Standard Accessories	Optional Accessories
Drill chuck Draw bar Arbor Digital depth ruler Toolbox & tools	Keyless drill chuck ER25 collect chucks WOA50 angle vice Stand Chip tray 58pcs clamping kits End mill
