Variable Speed Lathe

Brushless motor mini universal lathe machine for metal working

Model No.:BT180V
Max.Swing over bed:180mm
Distance between slider:110mm
Distance betwen centers:300mm
width of bed:100mm
Spindle taper:MT3
Tailstock taper:MT2
  • Product Detail
  • Accessories

BT180V Brushless motor mini universal lathe machine for metal working

● Precise manufacturing
● Heavily ribbed prism bed made of steel casting, inductively hardened and precision ground Hardened and ground bed guideways
● Hardened spindle nose (DIN 6350)
● Guaranteed true running accuracy of the spindle nose of better than 0.009 mm
● Automatic longitudinal/leading spindle drive
● With longitudinal slide, cross slide and top slide
● Right-/left-handed rotation switchable on the control panel
● Emergency-stop push button and low-voltage release
● Thrust bearing
● Leading spindle run on two porous bearings
● Large threading range due to set of change gears

Model No.
BT180V
Tailstock Travel
4
Number of spindle speeds
variable
Spindle bore
21mm
Carriage travel
276mm
Cross slide travel
75mm
Tool slide travel
55mm
Range of metric threads
0.5-2.5mm
Range of nch threads
10-44T.P.I
Tool post type
4
Spindle speed
50-2500rpm
Motor
550W
Voltage/Frequency
110-230/50-60HZ
Net Weight
60/65kg
Packing Size
740*370*390mm
Motor
Brushless motor as optional

Standard
Optional
3-jaw Chuck 80mm
MT2 Dead Center
Change gear set
Wrench set
Oil can
Splash guard
Chip tray
Toolbox &tools
4-jaw chuck(80/100mm)
Follow rest
Steady rest
Face plate
Quick change tool post
Rolling center
Stand
