Variable Speed Lathe

BT280V 1100KW mini bench lathe machine metal

Model:BT280

Swing over bed :280mm

Swing over cross slide:160mm
Distance between centers:550/610/815mm
Width of bed :150mm
Spindle bore:26mm
  • Product Detail
  • Accessories
1)Widely useful, like home hobby, Education, Factory use ect, operation easy.
2)Various speeds and thread cutting function are avaiable with gear box.
3)Induction-hardened and ground prismatic bed made from cast iron.
4)High precision and hardened spindle.
5)Safety magnetic and lock key European-standard switch.
6)Cost-efficient,precise and stable value.

Model BT280V
Spindle bore 26mm
Number of spindle speed
Variable speed
Range of spindle speed
80-1600rpm
Range of cross feed
0.036-0.364mm/rev
Range of metric thread
0.25-2.5mm
Top slide travel
60mm
Motor Power
1100W
NW/GW
245/270KG
Packing size
1500*614*647mm

Standard accessories
Optional accessories
Oil can
Chip tray
Wrench set
3-jaw chuck
Splash guard
Change gear set
Tool box or tools
MT2 dead center
Lead screw cover
Chuck cover
Working lamp
Live center MT3
2-axis digital readout
3-axis digital readout
Quick change tool post
Tapet turning attachment
