BT360 1M 1.5KW Chinese bench metal lathe machine projects

1)Widely useful, like home hobby, Education, Factory use ect, operation easy.

2)Various speeds and thread cutting function are avaiable with gear box.
3)Induction-hardened and ground prismatic bed made from cast iron.
4)High precision and hardened spindle.
5)Safety magnetic and lock key European-standard switch.
6)Cost-efficient,precise and stable value.

Models	BT360
Spindle number	8
Range of spindle speed	70-2000rpm
Cross slide travel	170mm(6-11/16")
Compound rest travel	95mm(3-9/16")
Lead screw thread	8T.P.I or 3mm
Feed rod diameter	19mm(3/4")
Cutting tool max section	16x16mm(5/8"x 5/8")
Threads imperial pitches	42 Nos. 4-112T.P.I
Threads metric pitches	44Nos. 0.1-7M.P
Threads diametral pitches	25Nos. 16-112mmD.P
Threads module pitches	34Nos. 0.1-1.75M.P
Longitudinal feeds imperial	24Nos. 0.00168-0.1175"rev
Longitudinal feeds metric	24Nos. 0.046-3.249mm/rev
Cross feeds imperial	32Nos. 0.00046-0.03231"rev
Cross feeds metric	24Nos.0.01-0.703mm/rev
Tailstock quill diameter	32mm(1-1/4") Or 42mm(1-21/32")
Tailstock quill travel	100mm(3-15/16")
Taper of tailstock quill	No3 morse
Motor	1.5kw(2HP)
Coolant pump power	40w(1/16HP)
Packing size	1680x760x1580mm
N.G weight	540/645kg

Standard Accessories	Optional Accessories
3-jaw chuck 4-jaw chuck Dead center Change gear set Wrench set Oil can Splash guard Chip tray Follow rest Steady rest Face plate Toolbox &tools Stand	USA Quick change tool post Lead screw cover Working lamp Cooling pump MT3 Rolling center CE Standard 51 spindle bore Foot brake Holder guard Digital readout(2 axis) Digital readout(3 axis) Tapet turning attachment
