. Ideal for processing of steel, non-ferrous metals and plastics
· Electro-magnetic foot brake reduces downtime
· Hardened and polished toothed gears also in feed drive
· Practical, solid machine featuring a lead screw and feed rod
· Grey cast-iron machine bed, inductively hardened and precisely polished
· State-of-the-art spindle bedding with high-quality, angular ball bearings
· Machine base in heavy cast iron construction
· Easy, smooth and precisely adjustable speed and feed settings
· Pull-out chip tray allows for minimum space requirements
· Removable bridge for processing of work pieces with a large diameter
· Serially equipped with slip clutch
Metric screw pitch |
26Nos.0.4-7mm |
D.P. imperial pitch |
36No. 8-112D.P |
M.P metric pitch |
23No. 0.25-3M.P |
Spindle drive motor |
4P/8P,3PH3.3/2.2kw |
Longitudinal feeds imperial |
0.002"-0.548"/Rev.(32Nos |
Longitudinal feeds metric |
0.052-1.392mm/ Rev.(32Nos |
Cross feeds imperial |
0.0007"-0.0187"/Rev.(32Nos) |
Cross feeds metric |
0.014-0.380mm/ Rev.(32Nos) |
Tail stock diameter |
50mm |
Tail stock travel |
114mm |
Tailstock taper |
MT4 |
Tail stock width |
10mm(±3/8") |
motor |
3HP,3PH |
Coolant pump motor |
1/8 HP,3PH |
Packing size(LxWxH) |
1940x800x1600mm
|
Machine size(LxWxH) |
1930x800x1258mm |
Net weight |
690kg |
Gross weight |
820kg |
