precision long bed lathe machine with cooling system

Model No.:BT660
Swing over bed:Ø800mm(31-1/2")
Swing over cross slide:Ø570mm(31-1/2")
Swing in gap diameter:1035mm(40-3/4")
Valid length of gap:250mm(10")
Distance between centers:1500mm(60'') 2000mm(80") 3000mm(120")
Width of bed:400mm(15-13/16'')
  • Product Detail
Model No.
BT660
Spindle nose
D1-8
Spindle bore
Ø105mm(4-1/8")
Taper of spindle bore
Ø113(1:20)
Range of spindle speed
25-1600r/min
Compound rest travel
230mm(9-1/8")
Cross slide travel
420mm(16-17/32")
Max.Section of tool
25x25mm(1"x1")
Lead screw thread
12mm or 2T.P.I
Longitudinal feeds range
0.044-1.48mm/rev(0.00165"-0.0550"/rev)
Cross feeds range
0.022-0.74mm/rev(0.00083"-0.02774"/rev)
Threads metric pitches
54 kinds,0.45-120mm
Threads imperial pitches
54 kinds,7/16-80T.P.I
Threads diametral pitches
42 kinds,7/8-160DP
Threads module pitches
46 kinds,0.25-60MP
Quill diameter
Ø90mm(3-1/2")
Tailstock travel
235mm(9-1/4")
Tailstock taper
No.5 Morse
Main motor power
7.5kW(10HP)3PH
Coolant pump power
0.1kW(1/8HP)3PH
Overall dimension(LxWxH)
321X123X167CM
371X123X167CM
471X123X167CM
Packing size(LxWxH)
324X114X191cm
374X114X191cm
474x114x191cm
Net Weight
3175kg
3455kg
3820kg
Gross Weight
3695kg
4005kg
4495kg
