BT800A Gap bed turning lathe machine for sale in Germany 103mm big bore

1. Integrated deluxe cast iron stand.
2. Hardened and ground bed guideways.
3. Electrical system with CE components.
4. Convincing arguments:quality,efficiency and price.
5. Head stock gears are made of high quality steel ground and hardened.

6. Emergency-stop push button,protective motor switch,lockable main switch.

LATHE MODEL	BT800A
Spindle hole	103mm
Spindle nose	ISO D11
Spindle taper	Metric 115
Spindle speed(Number)	(ccw/18steps)9-1276rpm (cw/6steps)16-816rpm
Max. travel of top slide	110mm
Max. travel of cross slide	325mm
Max. size of tool shank	32x32mm
Longitudinal metric feeds range	72kinds 0.072-4.066mm/rev
Cross metric feeds range	72kinds 0.036-2.033mm/rev
Metric threads range	72kinds 0.5-112mm
Inch threads range	72kinds1/4-56T.P.I
Moudle threads range	36kinds 0.5-7mm
Diametral threads range	36kinds 4-56DP
Dia.of tailstock sleeve	90mm
Taper of tailstock sleeve	MT6
Max.travel of tailstock sleeve	150mm
Main motor power	11Kw
Coolant pump motor	90W
Rapid travel motor	250W

Standard Accessories	Optional Accessories
Three- jaw chuck Four-jaw chuck Centers Driving plate Splash guard Steady rest Follow rest Face plate Coolant system Foot brake Toolbox&tool 1 set Stopper and localizer	Living center Taper turning attachment Drill chuck Quick change tool post Digital readout(2 axis/3 axis) Chuck cover Leadscrew cover Tool post cover
