CK6140 CNC metal spining lathe machine with auto lubrication coolant system
1. 400mm swing over bed
2. 500/750/1100/1500mm center distance
3. 4 or 6 or 8 tool carrier for choose
4. 60mm big spindle bore
5. GSK Siemens Fanuc control system available
6. Auto lubrication coolant system

Model No.	ck6140
Taper of spindle bore	MT6
Chuck	6''or8''
Range of spindle speed	150-2500rpm or 4/7m/min
X a-xis travel X	230mm
Z a-xis travel Z	750/1000/1500mm
X/Z Rapid speed X/Z	4/7m/min
Station of tool carrier	4 or 6 or 8
Max.Section of tool	20x20mm
Stroke of tailstock sleeve	120mm
Diameter/Hole of tailstock sleeve	55mm/MT4
Main motor power	5.5kw or 7.5kw
Coolant pump power	180w
Overall dimension(LxWxH)	2220/2540/3040x1420x1750mm
Packing size(LxWxH)	2420/2740/3420x1620x2100mm
Net Weight	1350/1500/1700/2100kg
Gross Weight	1550/1700/1900/2300kg

Standard Accessories	Optional Accessories
Wrenches Reduction sleeve Alloy center Three-jaw chuck Frequency main motor Four position electric turret Auto lubrication coolant system	AC servo motor Pneumatic or hydraulic chuck Spring fastener of pneumatic THorizontal six or eight-station
