BT200 220v Gear head mini bench lathe machine

Model :BT200
Max.Swing over bed :200mm
Max.Swing over carriage :115mm
Max.distance between centers:350mm or 520mm
Width of bed :125mm
Taper of spindle hole :MT3
Spindle bore:20mm

Product Detail
Accessories

BT200 220v Gear head mini bench lathe machine
1. 200mm swing diameter
2. 350mm or 520mm center distance
3. 20mm spindle bore
4. Powerful 550W motor
5. High spindle accurancy
6. Harden guidway

Turning diameter (Max.)	Ø200mm
Swing over cross slide	Ø115mm
Distance between centers	350mm/520mm (Optional)
Width of bed	125mm
Spindle bore	Ø20mm
Spindle taper	MT3
Spindle speed (6 steps)	140~1710rpm
Top slide travel	78mm
Cross slide travel	119mm
Max. section of tools	10x10mm
Range of metric threads	0.4~3mm
Range of inch threads	8~32 T.P.l
Tailstock quill diameter	Ø22mm
Tailstock quill travel	35mm
Taper of tailstock quill	MT2
Motor power	550w
Voltage	110V~240V(1PH)
Packing size	1050x570x570mm

Standard Accessories	Optional Accessories
Three- jaw chuck V-belt Dead centers Wrench Spanner Change Gears Wrench for tool post	Four jaw chuck Follow rest Steady rest Face plate Rolling center Stand Turning tools Splash guard Chip tray Back plate
