Drilling Milling Machine

BT20V 600W benchtop milling small mill drill machine for hobby sales

Model:BT20V
Max.Drilling Capacity:20mm
Max.End Milling Capacity:20mm
Max. Face Milling Capacity:63mm
Table Size:500x180mm/700x180mm
X-axis travel:280mm/480mm
Y-axis travel:175mm
Z-axis travel:270mm
  • Product Detail
  • Accessories

BT20V 600W benchtop milling small mill drill machine for hobby sales
Feature:
1) Very easy to operate
2) Head swivels 360°
3) Head worktable up&down vertically
4) Strong iron casting column
5) Wide and big table
6) Micro feed precision
7) Heavy-duty tapered roller bearing Spindle
8) Positive spindle lock
9) Adjustable gibs on table
10)  Belt drive, low noise

Mill & Drill
Max. drilling capacity Ø20mm
End milling capacity Ø20mm
Face milling capacity Ø63mm
Taper of spindle bore MT2
Spindle travel 50mm
Spindle speed 50~2250rpm
Head tilt left and right ±45°
Worktable
Working table size 500x180mm/700x180mm (Optional)
X-axis travel 280/480mm (Optional)
Y-axis travel 175mm
Z-axis travel 270mm
T slot 3x12mm
Distance between spindle and column 175mm
Motor power 750w
Packing size 870×550×860mm
N.W/G.W 110/135kg


Standard Accessories
Optional Accessories
Drill chuck 3-16mm;
Draw bar;Arbor;
Digital depth ruler;
Toolbox & tools;
Speed display
Keyless drill chuck 3-16mm;
Keyless drill chuck 3-16mm;
Vice;Stand Chip tray;
58pcs clamping kits;
End mill 7pcs 4-16mm;
X-axis power feed;
Digital readout
