BT360F Wholesale large lathe machine sec

BT360F Wholesale large lathe machine second hand lathe

Model:BT360F
Swing over bed:356mm(14'')
Swing over cross slide:220mm(8-5/8'')
Swing in gap diameter:506mm(20'')
Valid length of gap:145mm(5-11/16'')
Distance between centers:750/1000mm(30/40'')
Width of bed:206mm(8'')
Spindle nose:D1-4
Spindle bore:38mm(1-1/2'')or 51mm

Product Detail

Model	BT360F
Lead screw thread	4mm or 8T.P.I
Longitudinal feeds range	0.0012''-0.0294''/rev(Inch lathe)or 0.043-0.653mm/rev(Metric lathe)
Cross feeds range	0.0004''-0.01''/rev(Inch lathe)or 0.027-0.413mm/rev(Metric lathe)
Threads metric pitches	0.45-7.5mm(Inch lathe)or 0.4-7mm(Metric lathe)
Threads imperial pitches	4-112T.P.I(Inch lathe)or 4-56T.P.I(Metric lathe)
Tailstock diameter	Ø45mm(1-3/4'')
Tailstock travel	120mm(4-3/4'')
Tailstock taper	MT No.3
Main motor power(double speeds)	1.5/2.4KW(2/3HP)
Coolant pump power	0.04kw
Overall dimension(LxWxH)	182x74x125cm
Packing size(LxWxH)	193x76x158cm
Net Weight	730kg
Gross Weight	860kg
