BT410 Metal turning torno lathe machine

BT410 Metal turning torno lathe machine with taper attachments

Model:BT410
Max.swing over bed:410mm(16")
Max.swing over cross slid:255mm(10")
Swing in gap diameter:580(22")
Height of center:205mm(8")
Admist between:1000mm(40")/1500mm
Width of bed:250mm(10")

Product Detail
Accessories

Turning diameter (Max.)	Ø410mm
Swing over cross slide	Ø255mm
Swing in gap diameter	Ø580mm
Valid length of gap	190mm
Distance between centers	1000/1500mm
Center heigh	205mm
Width of bed	250mm
Spindle nose	D1-6
Spindle bore	Ø52mm
Taper of spindle bore	MT6
Spindle speed (16 steps)	45~1800rpm
Top slide travel	140mm
Cross slide travel	210mm
Max. section of tools	20x20mm
Range of metric threads (39 kinds)	0.2~14mm
Range of inch threads (45 kinds)	2~72T.P.I
Lead screw thread	6mm or 4T.P.I
Tailstock quill diameter	Ø50mm
Tailstock quill travel	120mm
Taper of tailstock quill	MT4
Motor power (double speeds)	2.2/3.3kw
Coolant pump motor	100w
Voltage	380V~440V (3PH)
Packing size	(2060/2560)x900x1640mm

Standard Accessories	Optional Accessories
Three- jaw chuck Four-jaw chuck Centers Splash guard Steady rest Follow rest Face plate Coolant system Foot brake Toolbox&tool 1 set	Driving plate Living center Taper turning attachment Drill chuck Stopper and localizer Quick change tool post Digital readout(2 axis/3 axis) Chuck cover Leadscrew cover Tool post cover
