ZJ5120 20mm Capacity front switch bench

ZJ5120 20mm Capacity front switch bench drill press machine with vice and laser

Model:ZJ5120
Max Drilling Diameter:20mm(1'')
Motor Power:450/550/750w
Chuck Capacity:5-20mm
Spindle Travel:80mm
Class Of Speed:16
Speed50/60Hz:180~2770/220~3320rpm

Product Detail
Accessories

ZJ5120 20mm Capacity front switch bench drill press machine with vice and laser

Model	ZJ5120
Spindle Taper	MT2
Max distance from spindle axis to surface of column	180mm
Max distance from spindle end to surface of table	685mm
Max distance from spindle end to surface of base	1175mm
Swing	360mm
Table Size	290x290mm
Base Size	460x270mm
Column Diameter	72mm
Height	1600mm
Net Weight/ Gross Weight	68/72kg
Packing Size	1140x490x275mm

STANDARD ACCESSORIES	OPTIONAL ACCESSORIES
Gear rim drill chuck(5-20mm)B16 Morse taper MT3 Front switch Wrench set Drill Chuck Drill chuck guard	Keyless drill chuck Machine vice Micro switch Laser Machine lamp
