Drill Press

ZJQ4116 16mm floor type vertical drill press machine

13-inch(16mm) Floor Drill Press
MODEL:ZJQ4116
5/8’’(16mm) Max.Chuck Capacity
13’’(325mm) Swing
16 Spindle Speeds
-45°~0°~+45° Table Tilt L&R
Optional Chuck Guard And Micro-switch
For CE Requirement
  • Product Detail
  • Accessories

ZJQ4116 16mm floor type vertical drill press machine

Model ZJQ4116
Max Drilling Diameter
16mm(5/8'')
Motor Power
375/450/550w
Chuck Capacity
3-16mm
Spindle Travel
80mm
Class Of Speed
16
Speed50/60Hz
180-2770/220-3320rpm
Spindle Taper
MT2
Max distance from spindle axis to surface of column
162.5mm
Max distance from spindle end to surface of table
450mm
Max distance from spindle end to surface of base
630mm
Swing
325mm
Table Size
290*290mm
Base Size
420*250mm
Column Diameter
72mm
Height
980mm
Net Weight/ Gross Weight
42/45kg
Packing Size
770x450x260mm


Standard Accessories
Optional Accessories
Gear rim drill chuck(3-16mm)
Morse taper MT2
Wrench set
Drill Chuck
Keyless drill chuck
Drill chuck guard
Machine vice
Front switch
Micro switch
Laser
