ZJQ4116B CE approval pillar vertical dri

ZJQ4116B CE approval pillar vertical drilling machine for metal drilling

Model:ZJQ4116B
Max Drilling Diameter:16mm(5/8'')
Motor Power:375/450/550w
Chuck Capacity:3-16mm
Spindle Travel:60mm
Class Of Speed:12
Speed50/60Hz:300~2550/360~3060rpm
Spindle Taper:MT2

Product Detail
Accessories

ZJQ4116B CE approval pillar Vertical Drilling Machine for metal drilling

Model	ZJQ4116B
Max distance from spindle axis to surface of column	155mm
Max distance from spindle end to surface of table	490mm
Max distance from spindle end to surface of base	610mm
Swing	310mm
Table Size	200x200mm
Base Size	420x250mm
Column Diameter	58mm
Height	950mm
Net Weight/ Gross Weigh	34/36kg
Packing Size	770x450x260mm

Standard Accessories	Optional Accessories
Gear rim drill chuck(3-16mm) Morse taper MT2 Wrench set Drill Chuck	Keyless drill chuck Drill chuck guard Machine vice Front switch Micro switch Laser
