Jiangsu Bestech Industrial Co., Ltd.
| Model | Z3040 |
|
Max.drilling capacity |
40mm |
|
Distance spindle axis to column generating line |
300~1300mm |
|
Diameter of column |
300mm |
|
Spindle taper |
MT4 |
|
Spindle travel |
280mm |
|
Spindle speeds range |
32~2500r/min |
|
Spindle speeds series |
16 |
|
Range of Spindle feeds |
0.10~1.25mm/r |
|
Mpindle Spindle feeds |
8 |
|
Distance spindle nose to working surface of base |
300-1320mm |
|
Dimension of worktable |
600X450X450mm |
|
Dimension of base |
2050X900X200mm |
|
Overall size |
2100X900X2300mm |
|
Power of Main motor |
3kw |
|
G.W/NW |
2500/2100kg |
|
Packing dimension |
235X106X245cm |
