BT560 7.5KW iron industrial metal lathe machine for sale craigslist

Model:BT560
Swing over bed:560mm
Max.swing over cross slide:355mm
Swing in gap diameter:785mm
Distance between centers:1000mm/1500mm/2000mm/3000mm
Width of bed:350mm
Spindle bore:105mm
  • Product Detail
Model
BT560
Spindle speed range
12 steps 25-2000 rpm
Threads metric pitches
47 kinds 0.2-14mm
Threads imperial pitches
60 kinds 2-112.P.I
Thread module pitches
34kinds 0.1-7 M.P
Tailstock quill diameter
75mm
Total travel of tailstock quill
180mm
Taper in tailstock quill
MT5
Spindle drive motor(double speeds)
7.5kw
Coolant pump motor
100W
N.W/G.W
2070/2460kg or 2160/2550kg or 2435/2840kg
Packing Size
2450/2900/3400*1190*1740mm
