BT250F Mini multi functional lathe mill

BT250F Mini multi functional lathe mill drilling combo machine

Model No.:BT250F
Center distance:550/750mm
Max. Swing over bed:250mm
Max. Swing over cross slide:150mm
Width of bed:135mm
Taper of spindle bore:MT4
Spindle bore:26mm
Range of spindle speed:125-2000,50-2500rpm
Range of inch thread:8-56TPI
Range of metric thread:0.2-3.5mm
Taper of tailstock quill:MT2

Product Detail
Accessories

2. Brushless motor available
3. Spindle speed readout
4. Quick lock tailstock
5. Most economical and widely used hobby lathe
6. High accurancy

Lathe
Turning diameter (Max.)	Ø250mm
Swing over cross slide	Ø150mm
Distance between centers	550/750mm (Optional)
Spindle bore	Ø26mm
Taper of spindle bore	MT4
Variablr speed	50~2500rpm
Top slide travel	70mm
Cross slide travel	120mm
Range of metric threads	0.2~3.5mm
Range of inch threads	8~56T.P.l
Tailstock quill travel	60mm
Taper of tailstock quill	MT2
Motor power	750w
Voltage/AC	110V~380V / 50~60Hz
Mill & Drill
Face milling capacity	Ø50mm
Taper of spindle bore	MT2/R8
Spindle travel	52mm
Max. drilling capacity	Ø16mm
Range of spindle speed	50~2250rpm
Motor power	600w
Head tilt left and right	±45°
Packing size	(1220/1400)x630x860mm

Standard Accessories	Optional Accessories
3-jaw chuck 125mm MT2 Dead center Change gear set Wrench set Oil can Splash guard Chip tray Drill chuck Toolbox &tools	4-jaw chuck(125mm) Follow rest Steady rest Face plate Lead screw cover Quick change tool post Rolling center
