BT290F Brushless motor metal lathe machi

BT290F Brushless motor metal lathe machine with milling head

Distance between centers:700mm

Swing over bed:290mm
Swing over cross slide:180mm
Width of bed:182mm
Taper of spindle bore:MT5
Spindle bore:38mm
Range of spindle speed:80-2000rpm
Taper of tailstock quill:MT3
Motor:1.5KW

Product Detail
Accessories

1. Brushless motor available

2. Spindle speed readout,
3. Quick lock tailstock
4. Harden guideway
5. high spindle accurancy

6. Most economical and widely used hobby lathe

Model	BT290F
Max. drilling capacity	Max. Ø20
Milling cap of end mill cutting head	Max. 63mm
Milling cap of end mill cutter	Max. 20mm
Taper of spindle bore	MT2/R8
Spindle speed	80-2000rpm
Spindle stroke	52mm
T-solt size	12mm
Max.distance spindle to table	380mm
Working rang	190mm
Motor	750w
N.G weight	310KG
Packing size	1450×700×1050mm

Standard Acceccories	Optional accessories
3-jaw chuck Oil can Chip tray Wrench set Splash guard Toolbox & tools Change gear set MT2 dead center	Lead screw cover Chuck cover Working lamp Live center MT3 2-axis digital readout 3-axis digital readout Quick change tool post Tapet turning attachment
