manufacture supply universal horizontal

manufacture supply universal horizontal metal lathe machine

manufacture supply universal horizontal metal lathe machine

Model:BT510
Swing over bed:510mm (20")
Max.swing over cross slide:305mm(12")
Swing in gap diameter:735mm
Distance between centers:1000mm(40")/1500mm(60")/2000mm(78")
Width of bed:350mm
Spindle bore:80mm/105mm

Product Detail
Accessories

Model	BT510
Spindle speed range	12 steps 25-2000 rpm
Threads metric pitches	47 kinds 0.2-14mm
Threads imperial pitches	60 kinds 2-112.P.I
Thread module pitches	34kinds 0.1-7 M.P
Tailstock quill diameter	75mm
Total travel of tailstock quill	180mm
Taper in tailstock quill	MT5
Spindle drive motor(double speeds)	7.5kw
Coolant pump motor	100W
N.W/G.W	2070/2460kg or 2160/2550kg or 2435/2840kg
Packing Size	2450/2900/340011901740mm

Standard Accessories	Optional Accessories
3-jaw chuck 4-jaw chuck Dead center Change gear set Wrench set Oil can Splash guard Chip tray Steady rest Face plate Toolbox &tools Stand Cooling pump Working lamp Foot brake Follow rest	Quick change tool post Quick change tool post Quick change tool post MT5 Rolling center CE(Chuck guard) Tapet turning attachment Holder guard 2 Axis Digital readout Lead screw cover Big bore 105mm 3 Axis Digital readout

Tags: metal lathe lathe machine universal lathe machine bench lathe manual lathe machine

PREVIOUS：BT460*1000mm china iron lathe hardinge lathe for sale

NEXT：precision long bed lathe machine with cooling system
