Vertical Drilling Machine

Z5032 portable drilling machine for sale philippines up right drill press

  • Product Detail

Z5032 portable drilling machine for sale philippines up right drill press

Model
Z5025 Z5032
Z5040 Z5040E Z5050
Machinery power feed
Electronic power feed

Max.drilling capacity (mm)
28 32
40
50
Max.tapping capacity
M22 M22
M24
M33
Distance from spindle center to column surface(mm)
250 300 350
375
Distance from spindle nose to worktable(mm)
125-825
720 770
80-800
Distance from spindle nose to base(mm)
1220 1200
1215
1325
Vertical travel of worktable(mm)
750 700
680
720/650(optional)
Spindle taper
MT3 MT4
MT4
MT4
Spindle stroke(mm)
130
160
180
210
Spindle speeds range(rpm)
75-3200

L:90-1800

H:1000-3200

50-1450
55-1450
Number of speeds (steps)
12 12 -
18
Speeds power feed range
NO
0.06/0.12/0.18
0.1/0.2
0.1/0.2/0.3/0.4
Diameter of column
100
125
150
180
Worktable size(mm)
380X380 460X460
560X560
580X580
Dimensions of base(mm)
360X535
620X450
735X510
860X580
Width of T-slot(mm)
14
14
18
18
Main motor(2 speed motor)(kw)
0.85/1.1
1.5
0.85/1.5
3
Cooling pump(w)
40(optional)
40
75
75
Packing size(LxWxH)(cm)
210X40X64
225X57X76
227X58X110
225X59X90
N.W/G.W(kg)
200/230
350 540/600
760/860
20'container Q'ty:
42 30 20
13
