Z5040 2 speed motor drilling tapping machine specification
|
Model |
Z5025 |
Z5032 |
Z5040 | Z5040E | Z5050 |
|
Machinery power feed |
Electronic power feed |
|
|||
|
Max.drilling capacity (mm) |
28 |
32 |
40 |
50 |
|
|
Max.tapping capacity |
M22 |
M22 |
M24 |
M33 |
|
|
Distance from spindle center to column surface(mm) |
250 | 300 |
350 |
375 |
|
|
Distance from spindle nose to worktable(mm) |
125-825 |
720 |
770 |
80-800 |
|
|
Distance from spindle nose to base(mm) |
1220 |
1200 |
1215 |
1325 |
|
|
Vertical travel of worktable(mm) |
750 |
700 |
680 |
720/650(optional) |
|
|
Spindle taper |
MT3 |
MT4 |
MT4 |
MT4 |
|
|
Spindle stroke(mm) |
130 |
160 |
180 |
210 |
|
|
Spindle speeds range(rpm) |
75-3200 |
L:90-1800 H:1000-3200 |
50-1450 |
55-1450 |
|
|
Number of speeds (steps) |
12 | 12 |
- |
18 |
|
|
Speeds power feed range |
NO |
0.06/0.12/0.18 |
0.1/0.2 |
0.1/0.2/0.3/0.4 |
|
|
Diameter of column |
100 |
125 |
150 |
180 |
|
|
Worktable size(mm) |
380X380 |
460X460 |
560X560 |
580X580 |
|
|
Dimensions of base(mm) |
360X535 |
620X450 |
735X510 |
860X580 |
|
|
Width of T-slot(mm) |
14 |
14 |
18 |
18 |
|
|
Main motor(2 speed motor)(kw) |
0.85/1.1 |
1.5 |
0.85/1.5 |
3 | |
|
Cooling pump(w) |
40(optional) |
40 |
75 |
75 | |
|
Packing size(LxWxH)(cm) |
210X40X64 |
225X57X76 |
227X58X110 |
225X59X90 |
|
|
N.W/G.W(kg) |
200/230 |
350 |
540/600 |
760/860 |
|
|
20'container Q'ty: |
42 | 30 |
20 |
13 |
|
