ZJQ4116K High precision mini bore hole d

ZJQ4116K High precision mini bore hole drilling press machine

Model:ZJQ4116K
Max Drilling Diameter:16mm(5/8'')
Motor Power:375/450/550w
Chuck Capacity:3-16mm
Spindle Travel:60mm
Class Of Speed:5
Speed50/60Hz:620~2620/740~3140rpm
Spindle Taper:B16

Product Detail
Accessories

ZJQ4116K High precision mini bore hole drilling press machine

Model	ZJQ4116K
Spindle Taper	B16
Max distance from spindle axis to surface of column	130mm
Max distance from spindle end to surface of table	400mm
Max distance from spindle end to surface of base	515mm
Swing	260mm
Table Size	250mm
Base Size	340x210mm
Column Diameter	58mm
Height	840mm
Net Weight/ Gross Weight	30/32kg
Packing Size	665x415x260mm

STANDARD ACCESSORIES	OPTIONAL ACCESSORIES
Gear rim drill chuck(3-16mm)B16 Morse taper Wrench set Drill Chuck	Keyless drill chuck Drill chuck guard Machine vice Front switch Micro switch Laser Machine lamp
