Milling Machine

BT16V Electric motor bench drill milling machine for sale

Model No.:BT16V
Max. drilling capacity:16mm
Max end milling capacity:16mm
Max. face milling capacity:50 mm

Table size:400x120mm

Table travel (X,Y):220x160mm

1. Variable speed
2. Big table size for optional
3. Headstock can swivel 90 degree
4. Spindle speed range 20-2250rpm
5. Brushless motor available

Model No.	BT16V
T-slot	3x10 mm
Spindle taper	MT2
Spindle stoke	50 mm
Step of spindle speeds	Variable
Angle of spindle speeds	20-2250rpm
Spindle incline angle	90
Distance from spindle to column	188mm
Distance from spindle nose to table	210mm
Motor	500W
Net weight	70/90 kg
Packing size	500x450x760mm

Standard Accessories	Optional Accessories
Drill chuck Draw bar Arbor Digital depth ruler Toolbox & tools	Keyless drill chuck ER25 collect chucks WOA50 angle vice Stand Chip tray 58pcs clamping kits End mill
