2)Various speeds and thread cutting function are avaiable with gear box.
3)Induction-hardened and ground prismatic bed made from cast iron.
4)High precision and hardened spindle.
5)Safety magnetic and lock key European-standard switch.
6)Cost-efficient,precise and stable value.
Model |
BT300F |
Cross slide travel |
190mm |
Tailstock quill travel |
70mm |
Taper of tailstock quill |
MT3 |
Motor |
1.5KW |
Drilling / Milling head |
BT20V |
Max. drilling capacity |
Max. Ø20 |
Milling cap of end mill cutting head |
Max. 63mm |
Milling cap of end mill cutter |
Max. 20mm |
Taper of spindle bore |
MT2/R8 |
Spindle speed |
50~2250rpm |
Spindle stroke |
52mm |
T-solt size |
12mm |
Max.distance spindle to table |
380mm |
Working rang |
190mm |
Motor |
750w |
N.G weight |
350kg |
Packing size |
1500×750×1060mm |
