2. Hardened and ground bed guideways.
3. Electrical system with CE components.
4. Convincing arguments:quality,efficiency and price.
5. Head stock gears are made of high quality steel ground and hardened.
6. Emergency-stop push button,protective motor switch,lockable main switch.
LATHE MODEL |
BT660A |
Swing over bed |
660mm(26") |
Max.swing over cross slide |
435mm(17") |
Swing in gap diameter |
860mm(34") |
Distance between centers |
2000/3000mm |
Width of bed |
400mm |
Spindle bore |
103mm |
Spindle speed range |
18 steps 9-1276rpm / 6 steps 16-816rpm |
Tailstock quill diameter |
90mm |
Total travel of tailstock quill |
150mm |
Taper in tailstock quill |
MT6 |
Spindle drive motor(double speeds) |
7.5kw |
Coolant pump motor |
90W |
N.W/G.W |
3750/4250KG 4050/4650KG |
Packing Size |
3680/4680*1130*2000mm |
