machine tornos swing diametro 1000 torno

Swing over bed:800mm (31")
Max.swing over cross slide:570mm(12")
Swing in gap diameter:1035mm
Distance between centers:1500mm(60")/2000mm(78")/3000mm

Width of bed:400mm

Spindle drive motor(double speeds):7.5kw
Coolant pump motor:100W
Packing Size:3240/3740/4740*1140*1840mm

  • Product Detail
  • Accessories
  • FAQS

Swing over bed
800mm (31")
Max.swing over cross slide
Swing in gap diameter
Distance between centers
Width of bed
Spindle bore
Spindle speed range
25-1600 rpm
Threads metric pitches
54 kinds 0.45-120mm
Threads imperial pitches
54 kinds 7/16-80T.P.I
Thread module pitches
42kinds 0.25-60M.P
Tailstock quill diameter
Total travel of tailstock quill
Taper in tailstock quill
Spindle drive motor(double speeds)
Coolant pump motor
3175/3695kg or 3455/4005kg or 3820/4495kg
Packing Size

Standard Accessories
Optional Accessories
3-jaw chuck
Steady rest
4-jaw chuck
Face plate
Dead center
European Toolbox &tools
Change gear set
Wrench set
Cooling pump
Oil can
Working lamp
Splash guard
Foot brake
Chip tray Follow rest
USA Quick change tool post
2 Axis Digital readout
Lead screw cover 1M/1.5M/2M/3M
3 Axis Digital readout
European Quick change tool post
Splash guard
Italian Quick change tool post
Motor 9kw
MT5 Rolling center
Holder guard Chuck guard
Tapet turning attachment

1: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )

2: What is your trade terms?
A : FOB, CFR and CIF all acceptable.

3:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .

4: What's your main products of your company?
A: We specialized in all kinds of machines ,such as Bench Lathes (manual and CNC), Drilling MIlling Machine, Drill Press, Bench Grinder, Table Saw and Band Saw,etc.

5: Where is our factory located? How can I visit there?
A : Our factory is located in Jiangsu Province, China. Sure. All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed.
