CK6132 CNC Lathe machine mini metal lathe cnc metal spinning machine

1). 320mm swing over bed

2). 500mm 750mm and 1000mm center distance
3). 4 or 6 tool carrier for choose
4). 40mm big spindle bore
5). Door equipped with a safety switch
6).  Bed guideways inductively hardended (HRC42-52)

7). Small-size CNC lathe, perfect for small series and training purpose

Model	CK6132
Chuck	6"
Range of spindle speed	150-2500rpm
X a-xis travel	180mm
Z a-xis travel	500/750/1000mm
X/Z Rapid speed	4/7m/min
Station of tool carrier	4 or 6
Max. Section of tool	16*16mm
Main motor power	2.2kw or 3.7kw
Coolant pump power	120w
Overall dimensions L*W*H	1600/1920/2100x1120x1750mm
Package size L*W*H	1815/2120/2300x1300x2000mm
Net weight	800/900/1050kg
Gross weight	950/1050/1200kg

Standard Attachment	Optional Equipment
GSK980TDC Numerical control system Wrenches Reduction sleeve Alloy center Three-jaw chuck Frequency main motor Four position electric turret Auto lubrication coolant system	AC servo motor Electric hand-wheel Pneumatic or hydraulic chuck Siemens808D ADVANCED Fanuc oi mate numeral control system
