Mini Lathe

BT180 Mini hobby metal torno lathe machine

Model No.:BT180
Center distance:200/300/350mm
Max. Swing over bed:180mm
Max. Swing over cross slide:110mm
Spindle taper:MT3
Tailstock taper:MT2
Chuck diameter:80/100 mm
Spindle bore:20 mm
  • Product Detail
  • Accessories

7" x 14" BT180 Mini hobby metal torno lathe machine
1). Variable speed
2). Spindle speed readout,
3). Quick lock tailstock
4). Most economical and widely used hobby lathe
5). V- way bed is precision ground
6). Spindle is supported by precision tapered bearing
7). Headstock is constantly oiled during operating
8). Power longitudinal feed allows threading.

Turning diameter (Max.) Ø180mm
Swing over cross slide Ø110mm
Distance between centers 300mm/350mm (Optional)
Width of bed 83mm
Spindle bore Ø20mm
Spindle taper MT3
Variable speed 50~2500rpm
Top slide travel 55mm
Cross slide travel 75mm
Max. section of tools 10x10mm
Range of metric threads 0.5~2.5mm
Range of inch threads 12~52 T.P.l
Tailstock quill diameter Ø22mm
Tailstock quill travel 50mm
Taper of tailstock quill MT2
Motor power 400w/550w
Voltage 110V~240V(1PH)
Packing size 810x310x320mm




Standard Accessories
Optional Accessories
3-jaw Chuck 80mm
MT2 Dead Center
Change gear set
Wrench set
Oil can
Splash guard
Chip tray
Toolbox &tools
4-jaw chuck(80/100mm)
Follow rest
Steady rest
Face plate
Quick change tool post
Rolling center
Tailstock chuck
Cutter
Stand
