BT32V Belt driven taiwan milling machine with special price
Feature:
1) Very easy to operate2) Head swivels 360°
3) Head worktable up&down vertically
4) Strong iron casting column
5) Wide and big table
6) Micro feed precision
7) Heavy-duty tapered roller bearing Spindle
8) Positive spindle lock
9) Adjustable gibs on table
10) Belt drive, low noise
Model No. |
BT32V |
Table travel (X,Y,Z) |
425/625x220mm |
T-slot |
3x14 mm |
Spindle taper |
MT3/R8 |
Spindle stoke |
70 mm |
Step of spindle speeds |
Variable |
Angle of spindle speeds |
50-2250rpm |
Spindle incline angle |
5 |
Distance from spindle to column |
190mm |
Motor |
1100W |
Net weight |
220/250kg~245/275kg |
Packing size |
710/850x890x1150 mm |
