Drilling Milling Machine

BT25V Variable speed vertical drilling and milling machine with DRO

Model:BT25V
Max. Drilling Capacity:25mm
Max. End Milling Capacity:16mm
Max. Face Milling Capacity:63mm
Table Size:500x180mm/700x180mm
X-axis travel:295mm/495mm
Y-axis travel:175mm
Z-axis travel:280mm
  • Product Detail
  • Accessories

Mill & Drill
Max. drilling capacity Ø25mm
End milling capacity Ø20mm
Face milling capacity Ø63mm
Taper of spindle bore MT3
Spindle travel 50mm
Spindle speed 50~2250rpm
Head tilt left and right ±45°
Worktable
Working table size 500x180mm/700x180mm (Optional)
X-axis travel 280/480mm (Optional)
Y-axis travel 175mm
Z-axis travel 270mm
T slot 3x12mm
Distance between spindle and column 195mm
Motor power 750w/1100w (Brushless Motor)
Packing size 710x710x890mm
N.W/G.W 125/150kg
