Variable Speed Lathe

China Engine Lathe Mini Bench Hobby Metal Lathe

Model No.:BT280
Center distance:550/610/815mm
Max. Swing over bed:280mm
Max. Swing over cross slide:160mm
Spindle center height:140mm
Width of bed:150mm
  • Product Detail
  • Accessories
Features:
1.Induction harden bedway.
2.Enough strong power motor.
3.Euro-safety magnetic switch or lock key switch.
4.Widely useful,operation very easy,processing scope widespread.

5.Cost-efficient,precise andof stable value.

Model No.
BT280
Max. travel of cross slide
130mm
Max. travel of top slide
65mm
Spindle bore
26mm
Range of spindle speed
L80-H1600rpm
Tailstock stroke
MT3
Taper of tailstock quill
60mm
Motor
1100w
Packing case length/width /height
1500x614x647mm
Motor type
ordinary brush motor
Voltage/Frequency
Customer requested

Standard Accessories
Optional Accessories
3-jaw Chuck 125mm
MT3 Dead center
Change gear set
Wrench set
Oil can
Splash guard
Chip tray
Toolbox &tools
4-jaw chuck(125mm)
Follow rest
Steady rest
Face plate
Cooling pump
Working lamp
Lead screw cover
Quick change tool post

Rolling center

Stand
